Features:
．125KHz Proximity /13.56MHz mifare Card Reader
．Read Range: Up to 10CM(125KHz)/5CM(13.56MHz)
．26/34bit Wiegand (default)
．Easy to install on Metal Door Frame or Mullion
．External LED Control
．External Buzzer Control
．Indoor / Outdoor Operation
．Solid Epoxy Potted
．Waterproof IP65
．Reverse Polarity Protection
Specifications:
|
|
|
|
Read Range
|
KR101EM: Up to 10CM, KR101MF:Up to 5CM
|
|
Reading Time (Card)
|
≤300ms
|
|
Power / Current
|
DC 6-14V / Max.70mA
|
|
Input Port
|
2ea (External LED Control, External Buzzer Control)
|
|
Output Format
|
26bit/34bit Wiegand (default)
|
|
LED Indicator
|
2 Color LED Indicators(Red and Green)
|
|
Beeper
|
Yes
|
|
Operating Temperature
|
-20° to +65°C
|
|
Operating Humidity
|
10% to 90% relative humidity non-condensing
|
|
Color
|
Black
|
|
Material
|
ABS+PC with texture
|
|
Dimension(W x H x T)mm
|
43 X 77 X 17mm
|
|
Weight
|
50g
|
|
Index of Protection
|
IP65
|
