• FDD-LTE / TDD-LTE

• DC-HSPA+/HSPA+/HSPA/HSDPA/WCDMA/UMTS

• EDGE/GPRS

• CDMA2000 EVDO/CDMA 1X

• IEEE 802.3

• IEEE 802.3u

• 5× 10/100Mb LAN (4XLAN, 1xWAN configurable)

• 1× RS-232

• 1(2)× SMA-K, 1(2)x SMA-RP antenna connectors

• 1× Standard SIM/R-UIM Slot (Daul SIM optional)

• 1× power connector

• NET

• WLAN

• WAN

• LAN (LAN1~LAN4)


• Static route

• RIPv2/OSPF dynamic route

   Power supply

• 7.5 - 32VDC

• Local or remote web browser (IE v8 or above)

• CLI/Telnet command

• M2M management platform (optional)

• SSH configure (optional)

• Standard: IEEE 802.11b/g/n

• WEP, WPA and WPA2 encryption

• Standard 150Mbps, 300Mbps optional

• AP, Client, station, bridge mode support

• IP packet/Domain/MAC filter

• NAT

• DMZ

• IPSec

• PPTP/L2TP client

• OpenVPN

• GRE/IPIP

• Idle: 180mA@+12VDC

• Single Module Communications: 210mA@+12VDC

• Dual Module Communications: 600mA@+12VDC

• Dimension: 176mm x 105mm x 25mm (not including antenna)

• Weight: 350g

• Operation temperature: -30~+70 degree

• Store temperature: -40~+85 degree

• Relative Humidity: <95% (non-condensing)

• Guarantee: one year

• CE

• FCC

• RoHS

• CCC

    EN 300 328 v 2.1.1 (2016-11)
     EN 301 489-52, EN 301 489-17, EN 301 489-1
     EN 301 908-1, EN 301 908-2, EN 301 908-13,
     EN 55023:2015
     EN 60950-1,
     EN 55024:2010
     EN 61000-3-2: 2014
     EN 61000-3-3:2013
     EN 62311:2008
